BNVD-1431

Description

BNVD-1431 MK2 is a multi-purpose binocular night vision device (BNVD). It uses standard MX-10160 18mm image intensifier tube (IIT) and can work with MX-11769 tubes after minor modifications. All specifications are designed and tested to meet the requirements of the elite law enforcement and special operation units. BNVD-1431 MK2 can be mounted or handheld. Its optical pods can be easily flipped 140°side-wards to help the user adapt different light conditions. The BNVD-1431 MK2 has a unique built-in gravity sensor which enable the device to automatically turn on and off according to its posture. When the user stop using the device and flip it up above the helmet or head mount, the device will power off automatically to prevent light exposure from the eyepiece and tube damage caused by continuous exposure to light sources in the sky. When equipped with auto-gating technology, the BNVD-1431 MK2 can swiftly adjust the image brightness and protect itself from sudden flashlight, enabling the user to react or fight back without removing the device. The housing is made of special fiber-enhanced polymer with high strength, high modulus and fire resistant properties, which ensure that the device can work through all harsh conditions The BNVD-1431 MK2 can run for more than 15 hours (at general temperature) when using a normal AA battery. When connected with external battery pack, the running time can be extended to more than 50 hours (battery packs are purchased separately). The BNVD-1431 MK2 is compatible with the US military standard PVS-14 lenses (#A3256342) , which can be easily sourced in the market and government issue (GI) system. It can also work with commercial 40-degree lenses, 51-degree lenses, and ultra-light resin lenses according to customers’ demands.

Dimensions: 5.0″(L) x 5.0″(W) x 3.0″(H)

Weight: 500g-580g (varies according to the choice of lenses)

Color: Black

Tube options: Gen2+ or Gen3 18mm image intensifier tube (White Phosphor or Green Phosphor)

FOV: 40° ± 2°

Magnification: 1.0x

Waterproof:IP68

Eyepiece Diameter:26mm

Flipping Angle of pods: 140°

Gain:Adjustable/Variable according to tube options

Mount standard: Standard Wilcox dovetail, quick&easy removal

Environmental durability: Working temperature: -40℃ ~60℃; Storage temperature: -55℃ ~70℃

Power: One AA Battery, or external battery pack

Battery Life: >15hours with single AA battery), or >50hours with a battery Pack (in common temperature)
